GTXGN-12 Soild Insulated Switchgear SIS
GTXGN-12
Quantity
Working Condition
- Altitude:≤1000m
- Ambient air temperature:-40℃~ +45℃
- Relative humidity: Monthly average≤90%; Daily average≤95%
- No obvious pollutions such as erosion or combustible gas; No frequent violent vibrations
- Earthquake intensity: 8 degree
Technical specification
Item | Unit | Data | |
Rated voltage | kV | 12 | |
Rated current | A | 630 | |
| Rated frequency | Hz | 50 | |
Rated power-frequency withstand voltage(1min) | kV | 42/48 | |
Rated lightning impulse withstand voltage | kV | 75/85 | |
Arc To Be Continued | 2.5kA/0.5s | ||
Cabinet Protection Grade | IP4X | ||
Operating Supply Voltage | V | DC:24/48/110/220 AC:110/220 | |
Product
GTXGN-12 Soild Insulated Switchgear SIS
GTXGN-12 Solid insulated Switchgear is a new generation of fully-insulated and fully-enclosed environment-friendly switchgear. All live parts are enclosed in epoxy resin housing with APG injection moulding, and the adjacent cabinets are connected by plug-in solid-insulated bus, so the switchgear will not be affected by external environment.
GTXGN-12 Solid-insulated Switchgear includes three cabinets of basic functional units: vacuum load switch cabinet, vacuum load switch & fuse cabinet combination, and vacuum circuit breaker cabinet, which applies to 10kV three phase AC 50Hz single busbar system. As an equipment to receive and distribute electric energy, it is provided with line control, protection, monitoring and communicat ion, and can be used in airport, subway, huge building, secondary substation and mining or industrial enterprises, especially suitable for those occasions with narrow place, poor environment, high altitude and maintenance free requirement.
