CT-VS1-MOP Spring Operating Mechanism
Energy storage motor adopt unidirectional permanent DC motor, technical parameter as Table:
Item | ZYJ220-53-216 | ZYJ110-53-216 | YJ220-53-216 | YJ110-53-216 |
Rated operate voltage (V) | DC220 | DC110 | DC220 | DC110 |
Rated power (W) | 40 | 40 | 40 | 40 |
Normal operating voltage range (V) | 85%-110% | 85%-110% | 85%-110% | 85%-110% |
Rated operating current(A) | 0.5 | 1.0 | 0.5 | 1.0 |
Motor energy storage time (s) | ≤8 | ≤8 | ≤8 | ≤8 |
Closing/Opening electromagnet adopt solenoid electromagnet, technical parameter as Table:
Rated operate voltage (V) | AC220 | AC110 | DC220 | DC110 |
Rated operating current(A) | 1.36 | 3.60 | 2 | 5.3 |
Rated power (W) | <300 | <396 | <440 | <583 |
Coil resistance at 20°C (Ω） | 54 | 10.3 | 106 | 20.5 |
Normal operating voltage range | Open at 65%~120% rated operate voltage; do not open when less than 30% rated operate voltage | |||
Close at 85%~110% rated operate voltage; do not close when less than 30% rated operate voltage | ||||
Manual energy storage is operated by the handle allocated with the mechanism, the operating force less than 100 (N.m)
Mechanism output angle 40 degree
Product Description
CT-VS1-MOP Spring Operating Mechanism
CT-VS1-MOP spring motor drive operating mechanism, modular design, independence mounting, will be used in VS1-12kV, VS1-24kV, ZN85-36kV indoor medium voltage vacuum circuit breaker, with equivalent closing power, its performances can meet requirements of IEC62271-100, GB1984 AC Medium Voltage Circuit Breaker and the product's Technical Conditions.
CT-VS1-MOP were motor operating mechanism functions including motor or manual energy-storage; electromagnet or manual closing/opening; overcurrent protection, to realize overcurrent protection, the controller holds functions of surge current, time delay and fast breaking.
