CT19BN(W) Spring Operating Mechanism
Item | Weight (kg) | High*Width*Deep (mm) | Motor input power (W) | Closing spring (mm) | Matched vacuum circuit breaker opening current (kA) |
| CT19BN | 40 | 440*360*160 | 250 | Φ10 | 31.5 |
| CT19BW | 45 | 550*360*160 | 250 | Φ10+Φ6 | 31.5 |
Closing/Opening electromagnet adopt solenoid electromagnet, technical parameter as Table:
Rated operate voltage (V) | AC110 | AC220 | DC110 Close | DC110 Open | DC220 Close | DC220 Open |
Rated operating current(A) | 4.3 | 3.8 | 2.3 | 4 | 1.16 | 2 |
Rated power (W) | <437 | <836 | <253 | <440 | <255 | <440 |
Coil resistance at 20°C (Ω） | 8.5±0.5 | 19.2±1.2 | 47±2.8 | 27.5±1.7 | 190±5 | 106±3 |
Normal operating voltage range | Open at 65%~120% rated operate voltage; do not open when less than 30% rated operate voltage | |||||
Close at 85%~110% rated operate voltage; do not close when less than 30% rated operate voltage | ||||||
Mechanism output angle 50-55 degree.
The combination and code of release: 104、114、1114、1134、400
CT19BN(W) Spring Operating Mechanism
CT19BN(W) spring operating mechanism is an improvement on CT19 spring operating mechanism, has much better stability and reliability. CT19BW spring operating mechanism will be used in 35kV (ZW7) outdoor pole mounting vacuum circuit breaker and other vacuum circuit breaker with equivalent closing power, CT19BN spring operating mechanism will be used in 35kV (ZN23) vacuum circuit breaker and other vacuum circuit breaker with equivalent closing power, its performances can meet requirements of GB1984 AC High Voltage Circuit Breaker and the product's Technical Conditions; all technical parameters meet or exceed IEC standard.
Two kinds of closing power energy-storages: motor or manual energy-storage; Three kinds of break-brake operations: break-brake electromagnet, over-current trip electromagnet and manual button; Two kinds of closing operations: closing electromagnet, manual button.
